BM SERİSİ MİKRO TERAZİLER

 BM SERİSİ MİKRO TERAZİLER 0.000001 G / 0.001 MG



BM SERİSİ MİKRO TERAZİLER 0.000001 g / 0.001 mg

MODEL KAPASİTE HASSASİYET KEFE KALİBRASYON
BM-20 22 g 0.001 mg (1 µg) Ø25mm Dahili
BM-22 5.1 g / 22 g 0.001 mg (1 µg)/ 0.01 mg Ø25mm Dahili

BM SERİSİ YARI MİKRO TERAZİLER 0.00001 g / 0.0001 g

MODEL KAPASİTE HASSASİYET KEFE KALİBRASYON
BM-252 250 g 0.01 mg Ø90mm Dahili
Kategoriler: ,

Açıklama

MODEL BM-20 BM-22 BM-252 BM-200 BM-300 BM-500
Weighing capacity 22g 5.1g / 22g1 250g 220 g 320 g 520 g
Minimum weighing value 0.001mg 0.001mg / 0.01 mg 0.01mg 0.1mg
Repeatability/Std Dev 0.0025mg (for 1g) 0.004mg (for 1g) / 0.01mg 0.03mg (for 100g) 0.1mg 0.2mg
Linearity ±0.010mg ±0.010mg / ±0.02mg ±0.010mg ±0.2mg ±0.3mg ±0.5mg
Stabilization Time (set to FAST) Approx. 10 sec. Approx. 10 / 8 sec. Approx. 8 sec. Approx. 3.5 sec.
Sensitivity Drift (10°C-30°C) ±2ppm/°C (when automatic self calibration is not used)
Operating temperature 5°C to 40°C (41°F to 104°F), 85%RH or less (non-condensing)
Display Refresh rate 5 times / second or 10 times / second
Measurement Units (Display mode) g, mg, oz, ozt, ct, momme, dwt, GN, tael, tola, messghal, pieces (counting mode), % (percent mode), Specific gravity
Counting mode Minimum unit mass = 0.1mg / Number of samples = 10, 25, 50 or 100 pieces
Percent mode Minimum 100% ref. mass = 10.0 mg / Minimum 100% display = 0.01%, 0.1%, 1% (depends on the reference mass stored)
Internal Memory 200 sets weighing data / 100 sets with date & time / 50 sets of calibration data
External Data Logger Store up to 5,000 weighing results with date & time to AD-1688 (standard)
Data Output GLP / GMP / GCP / ISO compliant. Outputs: balance manufacturer, model, s/n, balance identifi cation number, data, time of calibration, mass used, and space for signature.
Standard interface RS-232C, Quick USB, External key plug for optional foot switch (SW:128)
Internal Calibration Motor-driven internal calibration
External Calibration masses (g) 20, 10, 5, 2, 1 200, 100, 50, 20, 10 200, 100, 50 300, 200, 100, 50 500, 300, 200, 100, 50
Ionizer electrode pin life Approx. 10,000 hours of continuous use. (User replaceable)
Weighing pan diameter 25 mm (50 mm, 95 mm for weighing filters) 90 mm
Power consumption Approx. 30 VA (supplied by the AC adapter)
External dimensions / Weight 259 (W) x 466 (D) x 326 (H) mm / Approx.
Standard accessories AC adapter, Instruction manual, WinCT (CD-ROM), Weighing Data Logger (AD-1688), Long Tweezers for calibration mass (AD-1689), Standard Tweezers. BM-20/22 also includes two filter weighing pans, microfuge holders and 3 sizes of disposable pans.
